Nan-O-Sil ASD Colloidal Silica Significantly Reduces the Cycle Time in Injection Molding

PP unfilled, Nylon 6, unfilled, Nylon 66, 33% glass, PBT unfilled,
PC + 33% glass, PPS, PEEK, and Acetal

Nan-O-Sil ASD Data Sheet

Process Aid — Colloidal Silica

Typical Chemical Properties
Sodium 0.0051%
Aluminum 0.000081%
Iron 0.00027%
Magnesium 0.00015%
Moisture Content 0.07%

Physical Properties
Bulk Density 15.5 lbs/cft
Specific Gravity 0.2.1 g/cc
Refractive Index 1.46
Ignition Loss 0.54(wt. % @ 1000 c)
Behavior in Water hydrophilic
pH (5% Aqueous Slurry): 8.0
Particle Shape spherical
B.E.T, Surface Area (m2/g): 20-25
X-ray Form Amorphous
Particle Diameter (0.02-0.55 um
Thermal Conductivity 0.13 w/cmk
Appearance Fine White Powder
Optically transparent

Sample and commercial quantities are available for testing

Read More »

Material Safety Data Sheet (MSDS)

Nan-o-sil - ASD - Amorphous silicon dioxide

Section 1: chemical product & company identification

Product name: Nan-O-Sil ASD - Amorphous Silicon Dioxide Powder
Chemical family: silicon dioxide (amorphous silica)
Manufacture/distributor address: Corning Incorporated -

Energy Strategy Associates, Inc.
159 Riders Mills road
Old Chatham, NY 12136
(518) 794-0082

Section 2: Composition/information on ingredients

CAS # 7631-86-9 amorphous silica - limit exposures - no, section 12 info - no

Section 3: Hazards to Identification

Noncombustible, non-reactive solid material, exposure to dust may be irritating to eyes, nose, and throat. Avoid breathing, skin contact, and ingestion.

Section 4: First Aid Measure
Eyes:Injuries from particles should be treated by a physician
Skin:Cut and abrasions should be treated promptly with cleansing of affected area
Inhalation:Move person to non-contaminated area. Call physician if symptoms persist
Ingestion:No need for first aid is anticipated if material is swallowed

Section 5: Fire Fighting Measures
Flash point:na
Flammability limits:na
Auto ignition temp:na
Means of extinguishing: As for the surrounding fire
Hazardous combustion products: Material will proceed to a liquid and will form irritating and toxic gaseous metallic oxides at extremely high temperature

Section 6: Accidental Spill/Release Measures
Large/Small Spill:Collect spill using vacuum cleaner with hepa filter, place in closed container
Waste Disposal:Regulations vary; consult local authorities

Section 7: Handling and Storage
GeneralAvoid inhalation of dust, contact with skin and eyes. wash after handling. keep container closed and dry.
StorageStore in dry area

Section 8: Exposure Control/Personal Protection
Ventilation:Use appropriate local exhaust ventilation to keep exposure limits below regulated level
OSHATotal dust: 15 mg/m3; respirable fraction: 5mg/m3

Personal Protection Equipment

Eye protection:wear safety glasses with side shields
Skin protection:wear gloves
Protective clothing:coveralls
Respiratory protection:not normally needed. If permissible levels are exceeded use niosh approved dust respirator

Section 9: Physical and Chemical Properties
Physical State:solid, spherical particles
Softening pt:na
Odor and Appearance:white, odorless
Ph (5% aqueous slurry):8.0
Specific Gravity2.1
Solubility (in water):hydrophilic
Boiling Point:na
Freezing Point:na
Vapor Pressure: na
Evaporation pt: na
Percent Volatile: none
Viscosity: na
Vapor density: na

Section 10: Stability and Reactivity
Stability:stable, conditions to avoid: none known
Hazardous Polymerization:will not occur
Incompatibility:none known
Section 11:transportation information
Un Number:not applicable
Un Proper Shipping Name:not regulated
Un Class:not applicable
Un Packing Group:not applicable
imdgcode/icao-ti information:
not regulated
Us Rail Regulations:not regulated
Dot Regulation:not regulated

Section 12: Toxicological Information
Skin Irritation:primary irritation index: 0.0 non-irritant.
Primary Eye Irritation:non-irritant. Avg. draize scores: 0.0 after 48 hours.
Acute Oral Toxicity:non-toxic, ld 50 > 5 g/kg (rat)
Sensitization:no data
Ecotoxicity:not tested
Mobility:not soluble in water, not mobile in soil
Persistence/degradability:not applicable
Bio-accumulation:not applicable
Wgk Water Hazard Class:nwg (not water hazardous)

Section 13: Regulatory Information

National Registries

United States: TSCA (Toxic Substance Control Act inventory): all components are listed on or exempt under TSCA.
Europe (EU): EINECS (European Inventory of Existing Commercial Chemical Substances):all components are listed on or exempt under EINECS or have been notified to EINECS.
Canada: CEPA (Canadian Environmental Protection Act): all components are listed on or exempt under the DSL.
Japan: MITI (Ministry of International Trade and industry): list of existing chemical subs. No. 1-548(1-810)
Australia: AICS (Australian Inventory of Chemical Substances): all components are listed under the AICS.
Korea: ECL (Existing Chemicals List):all components are listed on or exempt under the ECL.
Philippines: PICCS (Philippine Inventory of Chemicals and Chemical Substances): all components are listed on or exempt under the PICCS.

Hazard Classification:

United Kingdom:control of substances hazardous to health regulations 1994- listed in guidance note eh40. Chemicals (hazard information and packaging for supply) regulations 199 listed.
Europe (EU): this material is not defined as a dangerous substance regarding EU directive 67/548/eec and its various amendments and adaptations. REACH pre-registration # 17-2119401626-46-000
Canada:not classified

US Federal Regulations:

Clean Water Act (CWA, 40 cfr 116): not listed
Clean Air Act amendments of 1990 (CAA section 112, 40 cfr 82): no components are listed as hazardous air pollutants. The product is not made with nor does it contain any class 1 or class 2 ozone depleting substances as defined under the 1990 amendments to the act.

Comprehensive Environmental Response, Compensation and Liability act (CERCLA, 40 cfr 302): the material is not a hazardous substance under CERCLA.

Superfund Amendments and Reauthorization Act, title 111 (SARA):

Emergency Planning and Community right-to-know Act (EPCRA, 40 cfr 355): does not contain any constituents that are identified as extremely hazardous substances.

SARA section 311 (40 cfr 370) MSDS requirements: not regulated

SARA section 312 (40 cfr 370): apply if the material is present at any one time in amounts equal to or greater than 10,000 pounds.

SARA section 313 (40 cfr 372): does not contain any of the substance identified under section 313 as toxic chemicals in excess of the de minimis concentrations necessary to be subject to this rule.

US State Regulations

California prop 65:not listed
US CONEG legislation:not determined

Section 14: Other Information

Hazardous material information system (ratings key: 4=highest hazard, 0=lowest hazard)

U.S.Ahealth 1
Fire hazard 0
Reactivity 0
Personal protection E
EU S phrasesS22: do not breathe dust
S25: avoid contact with eyes.
S26: in case of contact with eyes, rinse immediately with plenty of water and seek medical advice.
S37: wear suitable gloves.
